Simulate your first Lightning transaction on the Bitcoin regtest network Part 1 (MacOS)

This is a simulation of lightning transactions - a three-part series

ยท

7 min read

Objective

The goal of this article is to help you

  • configure the Bitcoin environment
    • create a Bitcoin wallet
    • create an address, give it a label
    • mine some blocks to that address
  • configure two Lightening nodes

๐Ÿ“œ Introduction

This was me after I recently started my journey in Bitcoin development. I felt so overwhelmed by the resources online mainly because I found out that certain information where either left out or now deprecated. so I was inspired to write my take on this topic because it confused me the most.

๐Ÿ“œ Requirements

To be able to follow along, you must have both bitcoind and lnd installed.

Below are two articles that helped me through this topic's installation, setup, and research phases.

Their work heavily inspires this article and has made use of references appropriately.

โš™๏ธ My system specs

  • Machine: MacBook Pro
  • Operating System: macOS Monterey
  • terminal: kitty
  • shell: ZSH
  • Editor: Neovim
  • Package Manager: Homebrew

๐Ÿ“œ The boring but very important stuff rick sleeping Before we get to copying and pasting stuff into our terminal(the fun part), let's look at what the internet has to say about the following:

  1. The lightning network and how it interacts with the Bitcoin network
  2. The various Bitcoin network modes.

"The Lightning Network is a second-layer protocol built on top of the Bitcoin blockchain. It enables faster and cheaper transactions by creating off-chain payment channels between users. These channels allow multiple transactions to occur without needing to be recorded on the main Bitcoin blockchain. Instead, only the opening and closing transactions of the channel are settled on the blockchain. This interaction reduces congestion on the Bitcoin network and enables microtransactions with almost instant settlement times."

๐Ÿ“ก The Bitcoin testnet network mode

"Itโ€™s a public test blockchain where the bitcoin does not have a real-world value that works similarly to the mainnet blockchain. In this way, it is safe to test out some functionality." source: https://studygroup.moralis.io/

๐Ÿ“ก The Bitcoin regtest network mode ๐Ÿ‘ˆ๐Ÿฟ (this is the mode we are going to be using)

"Regtest (regression test) mode creates a local private blockchain where you can adjust the parameters to what you want. You usually use this when it is not needed to communicate with other peers and blocks. An example of what you can do with the parameters is you can create blocks instantly"Source: https://studygroup.moralis.io/

๐Ÿ“ก The Bitcoin signet network mode

"Signet is a proposed new test network parallel to the Bitcoin network. Like testnet and regtest, developers would use signet as a testing environment. Unlike the Bitcoin mainnet or the other test networks, signet would use digital signatures to validate blocks, not a Proof-of-Work system."Source: https://river.com/

Now to the good stuff:

โš™๏ธ Configuring our Bitcoin environment

Step 1a

This part is very important. if you have gone over the Setting Up a Bitcoin/Lightning Network Test Environment as I suggested above you would realize that the author manually created a bitcoin.conf but we'll be using the one at /Users/user/Library/Application Support/Bitcoin/bitcoin.conf auto-generated while installing bitcoin core.

now let's open up the autogenerated bitcoin.conf file with our text editor

nvim /Users/user/Library/Application Support/Bitcoin/bitcoin.conf

Add these settings below

# Daemon Options
server=1
daemon=1
fallbackfee=0.00072
txindex=1
mintxfee=0.0001
txconfirmtarget=6

# Network Options
regtest=1
#signet=1
#testnet=1

[regtest]
# RPC Options
rpcport=18443
rpcuser=bitcoin
rpcpassword=bitcoin

# ZMQ Options
zmqpubrawblock=tcp://127.0.0.1:28332
zmqpubrawtx=tcp://127.0.0.1:28333
zmqpubhashtx=tcp://127.0.0.1:28332
zmqpubhashblock=tcp://127.0.0.1:28332

Now, you can run your Bitcoin node service and the following commands from the terminal. Ensure your Bitcoin backend is all set and ready to run your lightning network.

Take note of the corresponding outputs to make sure you're on the right track. please note that I have truncated some outputs.

Start bitcoin service

$ bitcoind

Output:

Bitcoin Core starting

ensure you are on regtest

$ bitcoin-cli  getblockchaininfo

output:

{
  "chain": "regtest",  // ๐Ÿ‘ˆ๐Ÿฟ just making sure we are on the 'regtest' network
  "blocks": 526,
  "headers": 526,
...
}

create a Bitcoin wallet

$ bitcoin-cli createwallet "my_first_regtest_wallet"

output:

{
  "name": "my_first_regtest_wallet"
}

Create an address (we'll be generating a legacy address)

Quick note: A legacy address refers to a format for cryptocurrency addresses that was used in older versions of the blockchain protocol. For example, in Bitcoin, legacy addresses typically start with the number "1". These addresses are still functional but are being gradually phased out in favor of newer address formats like Segregated Witness (SegWit) addresses, which offer benefits like lower transaction fees and improved scalability.

$ bitcoin-cli getnewaddress -addresstype legacy

output

mhF5zQHNn7wzaaQTpzRmtsNgPgFF94fxeY  //๐Ÿ‘ˆ๐Ÿฟ yours will be different

Assign a label to the address generated above to make it easy to identify it

 $ bitcoin-cli setlabel "mhF5zQHNn7wzaaQTpzRmtsNgPgFF94fxeY" "my_first_address"

get a list of all our generated addresses

 $ bitcoin-cli listreceivedbyaddress 1 true

output

[
  {
    "address": "mhF5zQHNn7wzaaQTpzRmtsNgPgFF94fxeY",
    "amount": 0.00000000,
    "confirmations": 0,
    "label": "my_first_address",
    "txids": [
    ]
  }
]

Mine some block to the address (This is important)

Quick note: I faced a sticky issue when trying to run my lncli commands and so after doing some research found a solution which was basically to generate some blocks check here to know more about the issue https://github.com/lightningnetwork/lnd/issues/1177#issuecomment-1100012559

 $  bitcoin-cli generatetoaddress 101 "mhF5zQHNn7wzaaQTpzRmtsNgPgFF94fxeY"

output

[
   "461c729e6afecd371a5dac52aa06955fbcaa41688b67d1130887a761ab972064",
  "793c537c37a6cea487b762fdb2ca0af6bf15797f5f8f9847fe07dcf982cdc6b4",
  "422a76fd34cbf65743416f1e256129935c04cd40cb81a80c891e28425f78974d",
  "1a987221c802116c70c18b2cdd1233ec906c0800835eac3fe9e489b17d911ce8",
  ...
]

Check our wallet info

$ bitcoin-cli getwalletinfo

Output

{
  "walletname": "my_first_regtest_wallet",
  "walletversion": 169900,
  "format": "sqlite",
  "balance": 137.50000000,
  "unconfirmed_balance": 0.00000000,
  "immature_balance": 471.87500000,
  "txcount": 122,
  "keypoolsize": 4000,
  "keypoolsize_hd_internal": 4000,
  "paytxfee": 0.00000000,
  "private_keys_enabled": true,
  "avoid_reuse": false,
  "scanning": false,
  "descriptors": true,
  "external_signer": false,
  "blank": false,
  "lastprocessedblock": {
    "hash": "0da2df1e8591e6ac00c1390fe397580b267c5b63a729f802e0bdd458aafb46f0",
    "height": 648
  }
}

โš™๏ธ Configuring two LND nodes

Step 1a

we'll be creating a base or root directory called .lnd using the mkdir Linux command. please note that this directory can be named anything you wish same

$ mkdir ~/.lnd/.lnd1
$ mkdir ~/.lnd/.lnd2

Create a configuration file and add the settings below then save it as lnd.conf in the .lnd1 directory.

[Bitcoin]

bitcoin.active=1
bitcoin.regtest=1
bitcoin.node=bitcoind

[Bitcoind]

bitcoind.rpchost=127.0.0.1
bitcoind.rpcuser=bitcoin
bitcoind.rpcpass=bitcoin
bitcoind.zmqpubrawblock=tcp://127.0.0.1:28332
bitcoind.zmqpubrawtx=tcp://127.0.0.1:28333

Step 1b

Now just like in step 1a above, Create a configuration file add the settings below, and then save it as lnd.conf in the .lnd2 directory.

[Application Options]

listen=0.0.0.0:9734
rpclisten=127.0.0.1:11009
restlisten=0.0.0.0:8180

[Bitcoin]

bitcoin.active=1
bitcoin.regtest=1
bitcoin.node=bitcoind

[Bitcoind]

bitcoind.rpchost=127.0.0.1
bitcoind.rpcuser=bitcoin
bitcoind.rpcpass=bitcoin
bitcoind.zmqpubrawblock=tcp://127.0.0.1:28332
bitcoind.zmqpubrawtx=tcp://127.0.0.1:28333

Quick note: Notice that the config above has different ports and settings for network, RPC, and REST connections configured. well, to mention a few reasons:

  • Each LND instance needs to listen on different ports to avoid conflicts.
  • You might want lnd1 and lnd2 to use different wallets or have different wallet configurations. _ You might configure different network settings for each LND instance. For example, one might be configured to run on the Bitcoin mainnet while the other runs on the Bitcoin testnet but note that it is required that you run the two LN nodes on the same network for the sake of running transactions between them

Step 2

lastly, let's configure some aliases so let's open up ~/.zshrc with our favourite text editor once again

nvim ~/.zshrc

Now add this to the bottom.

# local variables
export LND1_DIR="$HOME/.lnd/.lnd1"
export LND2_DIR="$HOME/.lnd/.lnd2"

# aliases
#lnd1
alias lnd1="lnd --lnddir=$LND1_DIR";
alias lncli1="lncli -n regtest --lnddir=$LND1_DIR"

#lnd2
alias lnd2="lnd --lnddir=$LND2_DIR";
alias lncli2="lncli -n regtest --lnddir=$LND2_DIR --rpcserver=localhost:11009"

This is the end of the first part of the series. we'll be going over some preliminary setup and configuration for a successful transaction between 2 lightning nodes in the next part


๐Ÿ“œ Conclusion

you feel rushed, don't you? Don't worry It took me close to a week to understand this so it's fine if you don't entirely get what's going on for now. check out some of these useful links below chainquery: bitcoin-cli documentation
